| Product Name | Rated Voltage DC (V) | Rated Current (A) | Breaking Capacity (A) | Typical Cold. Resistance (mOhms) | Typical Voltage Drop (mV) | Typical Pre-Arcing I²t (A²Sec) | Data Sheet |
|---|---|---|---|---|---|---|---|
06 000.0.25
|
63 | 0.250 | 50 | 3100 | 1435 | 0.0012 |
|
06 000.0.375
|
63 | 0.375 | 50 | 1600 | 1250 | 0.0028 |
|
06 000.0.5
|
63 | 0.500 | 50 | 1000 | 750 | 0.005 |
|
06 000.0.75
|
63 | 0.750 | 50 | 440 | 550 | 0.015 |
|
06 000.1
|
63 | 1 | 50 | 257 | 390 | 0.02 |
|
06 000.1.5
|
63 | 1.5 | 50 | 137 | 320 | 0.07 |
|
06 000.2
|
32 | 2 | 50 | 70.5 | 220 | 0.14 |
|
06 000.2.5
|
32 | 2.5 | 50 | 52 | 200 | 0.25 |
|
06 000.3
|
32 | 3 | 50 | 34 | 155 | 0.30 |
|
06 000.3.5
|
32 | 3.5 | 50 | 23 | 135 | 0.50 |
|
06 000.4
|
32 | 4 | 50 | 20.5 | 130 | 0.80 |
|
06 000.5
|
32 | 5 | 50 | 13.25 | 115 | 1.6 |
|
06 000.6
|
32 | 6 | 50 | 8.9 | 100 | 2.6 |
|
06 000.7
|
32 | 7 | 50 | 6.95 | 95 | 3.3 |
|
06 000.8
|
32 | 8 | 50 | 5.43 | 90 | 4.5 |
|
