SC250 Series - Socay Electronics-Gas Discharge Tube,TVS Diodes,ESD Diodes,Resettable Fuse,Thyristor,Chip Varistor,Metal Oxide Varistor,Radial Lead PTC,Spark Gap Protectors

Rows: 25
Use the filters above each column to filter and limit table data. Advanced searches can be performed by using the following operators:
<, <=, >, >=, =, *, !, {, }, ||,&&, **[empty]**, **[nonempty]**, **rgx:**
Learn more
TableFilter v0.0.9
http://koalyptus.github.io/TableFilter/
©2015-2025 Max Guglielmi
Close
? 清除筛选
Product Name	I_hold (A)	I_trip (A)	V_max (Vdc)	I_max (A)	P_dtyp. (W)	Maximum Time To Trip Current (A)	Maximum Time To Trip Time (Sec.)	R_min (Ω)	R_max (Ω)	R1_max (Ω)

SC250-020CW0D	0.02	0.04	220	3.0	2.0	0.10	10.0	80.0	180.0	280.0
SC250-030CW0D	0.03	0.06	220	3.0	1.3	0.15	10.0	40.0	90.0	140.0
SC250-050CW0D	0.05	0.10	220	3.0	1.0	0.25	8.0	24.0	55.0	86.0
SC250-060CW0D	0.06	0.12	220	3.0	1.0	0.30	10.0	22.0	32.0	51.0
SC250-080CW0D	0.08	0.16	220	3.0	1.0	0.40	3.0	14.0	22.0	25.0
SC250-080CW1A	0.08	0.16	250	3.0	0.8	0.35	4.0	20.0	35.0	280.0
SC250-080CW1A	0.08	0.16	250	3.0	0.8	0.35	4.0	20.0	35.0	280.0
SC250-110SW0D	0.11	0.22	250	3.0	1.0	0.55	0.75	7	11	17
SC250-120SW0A	0.12	0.24	250	1.2	1.0	0.36	15.00	6.0	12.0	16.0
SC250-120SW0B	0.12	0.24	250	3	1.0	1.0	2.0	6	11	16
SC250-120SW0D	0.12	0.24	220	3.0	1.0	0.60	12.5	8.0	12.0	19.0
SC250-120SW5D	0.12	0.24	220	3.0	1.0	0.60	8.5	6.0	10.0	15.0
SC250-145SW0D	0.145	0.29	220	3.0	1.0	0.725	2.5	3.5	6.0	10.0
SC250-160CW0D	0.16	0.32	220	3.0	1.5	0.80	10.0	3.5	7.8	12.0
SC250-180CW0A	0.18	0.65	250	10	1.5	3.0	0.5	1.6	3.2	4.0
SC250-180CW0D	0.18	0.50	220	3.0	1.5	0.90	15.0	1.6	3.2	5.0
SC250-200CW0D	0.20	0.40	220	3.0	2.0	1.0	15.0	3.0	6.5	9.8
SC250-250SZ0B	0.25	0.50	250	3	1.0	3	6	1.5	5	8
SC250-400SZ0D	0.40	0.80	220	3.0	3.5	2.0	20.0	1.20	1.90	2.90
SC250-600CZ0D	0.60	1.20	220	3.0	4.0	3.0	10.0	0.50	0.75	1.13
SC250-600SZ0D	0.60	1.20	250	3.0	4.5	3.0	15.0	0.80	1.40	2.50
SC250-900SZ0D	0.90	1.80	220	3.0	5.5	4.5	20.0	0.50	0.80	1.20
SC250-1000CZ0D	1.00	2.00	220	10	4.0	5.0	10.0	0.28	0.45	0.70
SC250-2000SZ0D	2.00	4.00	220	5.0	5.0	10	15.0	0.135	0.27	0.45
SC250-020CW0D	0.02	0.04	220	3.0	2.0	0.10	10.0	80.0	180.0	280.0
